INSTALLATION

INSTALLING FREEZER PANEL

3
! FOR SIDE BY SIDE MODELS - SKIP THIS STEP
APPLIES TO:
1.
Slightly loosen the bracket screws present on
freezer panel.
NOTE: Be sure that the refrigerator door(s) are
tightly closed.
2.
Slide panel onto drawer. Retighten the four
screws on each side attaching the bracket to the
1
drawer panel.
3.
Using the Phillips-head flat screws, fasten the
panel brackets to the drawer.
4.
To allow for later adjustment of the panel, do not
fully tighten the screws attaching the bracket to
the drawer.
IMPORTANT: When you have completed
installing all the panels, check for alignment.
The drawer panel will move up or down to align.
Completely tighten the screws only when panels
are fully aligned.
Parts to be used:
2
X6 Phillips-head screws
4
INSTALLATION | 17
