INSTALLATION

INSTALLING DOOR PANEL(S)

18 | INSTALLATION
APPLIES TO:
WARNING
1
Tip Over Hazard
Refrigerator is top heavy and tips easily
when not completely installed.
Install secondary anti-tip board to ensure
product stability.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or
serious injury.
2
NOTE:
Be sure that secondary anti-tip board is installed
before opening the door. Refer "INSTALLING
THE SECONDARY ANTI-TIP BOARD" section to
install the secondary anti-tip board.
For panel installation, it is recommended to have
product outside of kitchen cabinet not more than
8" (20.32 cm).
Raise the refrigerator until the top of the
refrigerator touches the bottom of secondary
anti-tip board.
3
Open only one door at a time.
1.
Open the door(s) and remove the hinge cover(s).
NOTE: French door and bottom mount models
have bottom hinge cover(s) that also must be
removed.
2.
Take out the door adjustment pin cover(s) to
expose the adjustment pins.
3.
Use foam packaging to prop and hold the door
open while installing a door panel.
