11.3.10.
Etat de conformité du protocole d'implémentation BACnet
Date :
Nom du vendeur :
Nom du produit :
Numéro du modèle :
Version du logiciel d'Application :
Révision du Firmware:
Revision du Protocole BACnet:
Description du produit :
Profile de produit standardise BACnet (Annexe L) :
BACnet Operator Workstation (B-OWS)
BACnet Advanced Operator Workstation (B-AWS)
BACnet Operator Display (B-OD)
BACnet Building Controller (B-BC)
BACnet Advanced Application Controller (B-AAC)
BACnet Application Specific Controller (B-ASC)
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)
List all BACnet Interoperability Building Blocks Supported (Annexe K):
DS-RP-B, DS-WP-B, DM-DDB-B, DM-DOB-B, DM-DCC-B, DM-RD-B
Capacité de Ségmentation:
Able to transmit segmented messages
Able to receive segmented messages
Type d'Objets standards supportés:
An object type is supported if it may be present in the device. For each standard Object Type supported provide the following data:
1) Whether objects of this type are dynamically creatable using the CreateObject service
2) Whether objects of this type are dynamically deletable using the DeleteObject service
3) List of the optional properties supported
4) List of all properties that are writable where not otherwise required by this standard
5) List of all properties that are conditionally writable where not otherwise required by this standard
6) List of proprietary properties and for each its property identifier, datatype, and meaning
7) List of any property range restrictions
Options Data Link Layer:
BACnet IP, (Annex J)
BACnet IP, (Annex J), Foreign Device
ISO 8802-3, Ethernet (Clause 7)
ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
ATA 878.1, EIA-485 ARCNET (Clause 8), baud rate(s):
MS/TP master (Clause 9), baud rate(s): 9600, 19200,38400,76800
MS/TP slave (Clause 9), baud rate(s):
Point-To-Point, EIA 232 (Clause 10), baud rate(s):
Point-To-Point, modem, (Clause 10), baud rate(s):
LonTalk, (Clause 11), medium:
BACnet/ZigBee (ANNEX O)
Other:
Adresse appareil obligatoire (Device Address Binding):
Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain other devices.)
Yes
No
Options mise en réseau:
Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
Annex H, BACnet Tunnelling Router over IP
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices?
Does the BBMD support network address translation?
Options de Sécurité du réseau:
Non-secure Device - is capable of operating without BACnet Network Security
Secure Device - is capable of using BACnet Network Security (NS-SD BIBB)
Multiple Application-Specific Keys:
Supports encryption (NS-ED BIBB)
Key Server (NS-KS BIBB)
Jeux de caractères Supportés:
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
ANSI X3.4
ISO 10646 (UCS-2)
If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the gateway supports.
48
Guide de l'Utilisateur pour variateur Optidrive Eco Révision 2.01
15 Avril 2015
Invertek Drives Ltd
OPTIDRIVE ECO
ODV-3-xxxxxx-xxxx-xx
2.00
2.00
7
Invertek Optidrive Eco
Window Size
Window Size
IBM /Microsoft
DBCS
ISO 8859-1
ISO 10646 (UCS-4)
Yes
No
Yes
No
JIS X 0208
