6.0 MAINTeNANce, seRvIcING, ANd sTORAGe
6.1 wASHING INSTRUCTIONS: Washing procedures for the ExoFit NEX™ Full Body Harness are as follows:
Step 1. Spot clean the ExoFit NEX™ full body harness with water and a mild soap solution. The harness
may be laundered by using a bleach-free detergent. Water temperature for wash and rinse must
not exceed 160° F (70° C).
Step 2. Place the harness in the supplied laundry bag. The bag is designed to prevent entanglement of
harnesses and to protect the washing machine from damage. Use of the laundry bag to wash the
pads is optional.
NOTe: Use a bleach-free detergent when washing the harness and pads.
Step 3. The harness and pads may be air dried or tumble dried on low heat not exceeding 200° F (90° C).
NOTe: More information on cleaning is available from Capital Safety. If you have questions concerning
the condition of your harness, or have any doubt about putting it into service contact Capital Safety.
6.2 ADDITIONAl MAINTENANCE AND SERVICING: Additional maintenance and servicing procedures must
be completed by a factory authorized service center. Authorization must be in writing. Do not attempt to
disassemble the unit.
6.3 STORAGE: Store the ExoFit NEX™ Full Body Harness in a cool, dry, clean environment out of direct sunlight.
Avoid areas where chemical vapors may exist. Thoroughly inspect the full body harness after extended
storage.
7.0 sPecIFIcATIONs
7.1 PERFORMANCE:
• Maximum Free Fall Distance:
NOTe: Harness is acceptable for use with free fall distances exceeding 6 feet (1.8 m) if used with
appropriate connecting system.
• Maximum Arresting Force:
• Maximum Capacity:
• Approximate weight:
Harness only: 3 lbs. (1.4 kg)
Harness with Side D-rings: Add 1/2 lb. (.23 kg)
Harness with Front D-ring: Add 1/4 lb. (.11 kg)
Harness with Back Pad or Belt: Add 1 lb. (.45 kg)
7.2 MATERIAlS:
• webbing Materials:
Tensile Strength Nomex
• Pad and label Cover Materials:
• All outer fabric is Nomex and Kevlar blend fabric.
• Fire Resistant Hook and Loop Fasteners
• Blend of Nylon and Polyester
• Optional Accessories:
• Hip Pad with side D-rings
• Nomex covered Kevlar
®
• Non-sparking/ Non-conductive PVC coated hardware
• Arc-rated hip, leg, and back pads
• Polyurethane coated, arc-rated dorsal web loop
7.3 STANDARDS: When installed and used per the requirements and recommendations in the manual, the
ExoFit NEX™ Full Body Harness meets local, state, and federal requirements defined in Section 1.2.
4 ®: Nomex and Kevlar
® ®
No greater than 6 ft (1.8 m), per federal law and ANSI Z359.1.
1,800 lbs. (13 kN)
420 lbs. (191 kg)
6,000 lbs (27 kN) Polyester; 7,000 lbs (31 kN) Tensile Strength Nylon; 7,000 lbs
covered Kevlar
4
webbing
®
are registered trademarks of DuPont.
4
