MANUEL FR MODULE DE COMMUNICATION EASY-B
V 1.2

EB-MODBUS-RTU

7. Aperçu du registre
The following data can be set or retrieved via EB-MODBUS-RTU.
7.1 EB-MODBUS-RTU
Tableau 1 : Vue d'ensemble du registre EB-MODBUS-RTU
Function
Query status output 14
READ_COIL_Status
Query status output 24
READ_COIL_Status
Query device ID
READ_HOLDING_REGISTERS
Query options
READ_HOLDING_REGISTERS
Query supply voltage
READ_HOLDING_REGISTERS
Set options
WRITE_MULTIPLE_REGISTERS 16
BLOCK Transformatoren-Elektronik GmbH
Max-Planck-Straße 36-46
27283 Verden Germany
•
Query
Starting
Address Value
1
1 0x00 Off
0x01 Switched off by circuit breaker function (tripped)
2
1 0x00 Off
0x01
4
3 1-2. byte Firmware version
3-6. byte Production order
7-10. byte Serial number
11-12. byte Variant (see EB variants)
5
3 high byte Options (see Options)
low byte Options (see Options)
high byte Options Complement (see Options)
low byte Options Complement (see Options)
6
3 high byte Voltage in mV
low byte Voltage in mV
5
high byte Options (see Options)
low byte Options (see Options)
high byte Options Complement (see Options)
low byte Options Complement (see Options)
Phone +49 4231 678-0
•
info@block.eu
block.eu
•
Response
Description
Switched on, current above warning threshold (90% nominal
current)
For all devices in the network
Fax +49 4231 678-177
22.10.2024 / FRAN
Sous réserve de modifications techniques
14
