4
ADDING THE DEVICE TO Z-WAVE NETWORK
• In case of problems with adding, removing, or using S1 or S2 wall switch, use the PROG-button instead (located on the housing). The device
tries to add itself after pressing the button 3 times.
4.1 - Adding the device to the Z-Wave network manually
1. Place On/Off-Control2 within the direct range of your Z-Wave controller.
2. Set the main controller in the (security/non-security) add mode (for more information, see the controller manual).
3. Press quickly three times S1 or S2 switch or the PROG button.
4. Wait for the adding process to end.
5. Successful adding is confirmed by the Z-Wave controller message and the green LED diode when adding the device to the non-secure, S0,
S2 Unauthenticated mode or magenta LED diode when adding the device to the S2 Authenticated mode.
4.2 - Adding device using the SmartStart method
1. Enter the full DSK string code to your controller. If your controller is capable of QR scanning, scan the QR code placed on the label.
2. Power the device (turn on the mains voltage).
3. The LED indicator starts blinking yellow, wait for the adding process to end.
4. Successful adding is confirmed by the Z-Wave controller message and the device LED indicator:
Green – successful (non-secure, S0, S2 non-authenticated)
Magenta – successful (Security S2 Authenticated)
Red – not successful
5
REMOVING THE DEVICE FROM Z-WAVE NETWORK
You can remove the device from the Z-Wave Network using switches (S1 or S2) for 10 min. after powering the device.
To remove the device from the Z-Wave network:
1. Place On/Off-Control2 within the direct range of your Z-Wave controller.
2. Set the main controller in the (security/non-security) remove mode (for more information, see the controller manual).
3. Press quickly three times S1 or S2 switch or the PROG button.
4. Wait for the removing process to end.
5. Successful removing is confirmed with the Z-Wave controller message and the red LED diode.
6
OPERATING THE DEVICE
6.1 - Controlling On/Off-Control2 with the PROG-button
On/Off-Control2 is equipped with the PROG-button, which enables using the menu and performing actions listed in the table below:
Table 2 - On/Off-Control2 - PROG-button actions
Action Result
1x click • Select a desired menu position (if menu is active)
• Turn ON/OFF both channels (the 1
3x click Send the Node Info Z-Wave command frame (adding/removing)
Hold Enter the menu
6.2 - Resetting On/Off-Control2
1. Switch off the mains voltage (disable the fuse).
2. Remove On/Off-Control2 from the wall switch box.
3. Switch on the mains voltage.
4. Press and hold the PROG-button to enter the menu.
5. Wait for the visual LED indicator to glow yellow.
6. Quickly release and click the PROG-button again.
7. After a few seconds the device is restarted, which is signalled with the red LED indicator color.
4
and 2 )
st nd
