2. Press and hold down the on/off switch.
3. Release the switch-on interlock.
The switch-on interlock remains in the disengaged position as long as you hold down the on/off
switch or the plunge unit is in a plunge position. The switch-on interlock automatically snaps to the
engaged position when the plunge unit is in the basic position and you release the on/off switch.
Switching off
4. Return the plunge unit to the basic position.
5. Release the on/off switch.
6.2 Dust and chips management
• Sawing with dust extractor:
Connect the suction hose to the dust removal connector and follow the instructions in the operating
instructions for the dust extractor.
• Sawing with dust bag:
Connect the dust bag with the adapter to the dust removal connector for dust extractor.
You can also operate the product without dust collection method. Make sure that sawdust and chips
can be ejected without obstruction.
6.3 Sawing along a line
Saw only flat workpieces that offer a big enough contact surface to accommodate the whole of the
base plate.
1. Secure the workpiece to prevent movement and mark the line of cut (cutting mark).
2. Set the cutting depth.
3. Position the product with the adaptive cutting line indicator aligned with the marked line.
4. Switch the product on.
▶ The plunge movement of the product is possible only with the on/off switch unlocked.
5. Plunge the plunge unit all the way into the workpiece (1).
6. Guide the tool through the workpiece at a suitable speed.
7. With the saw blade running, swivel the plunge unit back to the basic position (2).
In this way you prevent the saw blade from binding in the workpiece.
8. Switch the product off as soon as the plunge unit is in the basic position.
6.4 Making a plunge cut
1. Set the cutting depth.
2. Position the product on the workpiece.
3. Switch the product on.
▶ The plunge movement of the product is possible only with the on/off switch unlocked.
4. Plunge the product all the way into the workpiece.
5. Guide the tool through the workpiece at a suitable speed.
6. Pivot the product out of the workpiece.
7. Switch the product off as soon as the plunge unit is in the basic position.
6.5 Making bevel cuts (angled cut)
The product has an adaptive cutting line indicator that adapts automatically to the set cutting angle. The
adaptive cutting line indicator applies only to cuts made without guide rail. When cuts are made with the
guide rail, the design of the product is such that the cutting line is independent of the set cutting angle.
1. Set the cutting angle for bevel cuts.
