Generac RTS-CSA Manuel Technique page 17

ITEM PART NO. QTY.
1 0C2237 1
2 0E6423 4
3 077033 6
4 0G7624 6
5 022152 6
6 074138 3
7 0E7886H 1
8 0E7890 1
9 0H5314 1
10 074908 2
11 0H5876 1
12 0C6748 15
13 0H5743A 1
14 0H5743B 1
15 0E3717 2
16 0H4695 1
17 0G7226 1
18 0G8411 5
19 0C3992 1
20 026850 3
21 0H5747 1
22 0G6320 1
23 022097 2
24 085889 2
25 0H5744 1
33 036949 6
34 0E7213 1
35 0E6303 2
36 0E6303C 1
(1)37 0H1605 1
38 0H5460 2
39 0E6193 1
40 0D6162 2
100A Transfer Switch Assembly – Drawing No. 0H5533$-A
DESCRIPTION
XFRSW HSB 200A 2P 250V
NUT HEX FL WHIZ M5-0.8
LUG SOLDERLESS 2/0-#14 x 9/16
AL/CU
SCREW PPHM #10-32 X 5/16
WASHER LOCK #10
LUG DIS QK NI-S 10X4
CB 0100A 2P 240V S BQ2 LB
BRKT CB MTG BACK
CB RISER 100 AMP CSA
SCREW HHTT M5-0.8 X 10
PAD LOCKING DEVICE 2" WIDE
NUT HEX LOCK M4-0.7 SS NYL INS
WIRE, 2 AWG BLACK N1A
WIRE, 2 AWG BLACK N2A
ASSY-NEUT BLK 100A W/TAP
BUSBAR NEUTRAL BLOCK
SPACER .171"ID .312 LG BRASS
NUT HEX FL WHIZ 1/4-20
SCREW HHTT M4-0.7 X 16
WASHER SHAKEPROOF EXT 1/4 STL
WIRE, 2 AWG WHITE NEUTRAL
GROUND BAR (5)2-14 AWG CONN
WASHER LOCK M6-1/4
NUT HEX 1/4-20 STAINLESS STEEL
HARNESS 200A CSA SERV ENT
1/4-20 X 1/2" SCREW, PPHM
SCREW THUMB 1/4-20 X1/2 W/SHLD
WIRE A 7.0"
WIRE E1 3.0"
BLOCK TERM 20A 5 X 6 X 1100V
STANDOFF, HEX M4-0.7 X 10
BRACKET, ARM EXTENDER
RIVET POP .156 X .362 AL
Section 6 — Exploded Views and Parts List
RTS "HS" Type Transfer Switch
ITEM PART NO.
41 0H5405
(1)42 063617
(1)43 0D2806
44 073590A
45 058000E
46 063212
47 072252
48 0C2262
49 0C2380
50 0D3587
51 0E3484
52 0G3259
53 0G4220
54 0G9651A
55 0G9651B
56 0G9651C
57 0H0497
58 0H1558
59 0H53130AL14
60 0H53150AL14
61 0H53160AL14
62 0H53170AL14
63 0H53180AL14
64 0H53200AL14
65 0H53210AL14
66 0H5333A
67 0H5388
(1) INCLUDED WITH HARNESS
QTY. DESCRIPTION
1 ARM EXTENDER PIN CSA
1 RELAY PNL 12VDC DPDT
10A@240VA
1 FUSEBLOCK 30A 600V 2POS W/SQ
2 FUSE 5A X BUSS
7 NUT TRIC 1/4-20 X .525
1 GROMMET 1.75 X .12 X 1.50
1 GROMMET 1.37 X .06 X 1.00
1 DECAL TERMINAL STRIP
1 DECAL,TRANSFER SWITCH ID 200A
1 DECAL, FUSE REPLACEMENT
1 DECAL WARN MANUAL OPER
HANDLE
1 DECAL TERMINAL SHOCK HZD BI
1 DECAL, NEUTRAL CONNECTION
1 DECAL, UTILITY SOURCE CONN
1 DECAL, GENERATOR/CUSTOMER
CONN
1 DECAL, UTILITY DISCONNECT
1 DECAL, RTS SERVICE ENTRANCE
TRANSFER SWITCH
1 DECAL TEST SEQUENCE
1 BRACKET UTILITY SEPERATION CSA
1 INSIDE COVER UTILITY SIDE
1 INSIDE COVER SWITCH SIDE
1 BRACKET ENCLOSURE SEPARATION
1 BRACKET,LOCK OUT
1 ENCLOSURE 100 AMP CSA
1 COVER CSA 100 AMP
1 DECAL,XFER SW SE 120/240
1 DECAL LIVE CIRCUIT
