ITEM PART NO. QTY.
1 0D9618 1
2 0E6423 5
3 0E3375 4
4 022097 6
5 0F1252 4
6 0E6033 2
7 0E6034 3
8 0E6303 2
9 0E6303B 1
10 0G4478 1
11 053640 2
12 0F8451 2
13 0F8843 2
14 049897 4
15 022145 2
16 022129 6
17 045771 2
18 043107 2
19 0E3717A 2
20 0G8411 7
21 026850 3
22 0H4695 1
23 0G6320 1
24 085889 2
25 0H0109 1
26 0H0107 1
27 0H0110 1
28 0H0111 1
29 0H4262 1
30 0H4285 1
31 0H4553 1
32 0H4581 1
33 0H4555 1
34 0H5000A 1
35 0H5000B 1
36 0H5001 1
200A Transfer Switch Assembly – Drawing No. 0H4557$-A
DESCRIPTION
XFRSW HSB 200A 2P 250V
NUT HEX FL WHIZ M5-0.8
LUG SOLDERLESS 250MCM-#6 AL/
CU
WASHER LOCK M6-1/4
SCREW BHSC 1/4-20 X 3/8
90 DEGREE DN SPADE CONNECTOR
STRAIGHT SPADE CONNECTOR
WIRE A 7.0"
WIRE E1 3.0"
CB 200A 2 POLE 240V 225AF
SCREW RHM #8-32 X 3-1/4
MACHINE SLOTTED
LUG SLDLSS 300 MCM-6 AL/CU
BUS BAR 200A LUG ADAPTOR
SCREW LOW HEAD SOCKET HEAD
(METRIC COARSE)
WASHER FLAT 5/16-M8 ZINC
WASHER LOCK M8-5/16
NUT HEX M8-1.25 G8 CLEAR ZINC
SCREW HHC M8-1.25 X 25 G8.8
ASSY-NEUT BLK 200-400A W/TAP
NUT HEX FL WHIZ 1/4-20
WASHER SHAKEPROOF EXT 1/4 STL
BUSBAR NEUTRAL BLOCK
GROUND BAR (5)2-14 AWG CONN
NUT HEX 1/4-20 STAINLESS STEEL
ENCL NEMA 3R CSA SER ENT
BRACKET ENCLOSURE SEPARATION
INSIDE COVER UTILITY SIDE
INSIDE COVER SWITCH SIDE
COVER CSA 200 AMP
RISER CIRCUIT BREAKER CSA
BRACKET CB LOCKOUT
BRACKET CIRCUIT PROTECTION
HARNESS 200A CSA SERV ENT
WIRE, 3/0 N1A
WIRE, 3/0 N2A
WIRE, NEUTRAL JUMPER
Section 6 — Exploded Views and Parts List
RTS "HS" Type Transfer Switch
ITEM PART NO.
(1)37 024334
38 0E7213
39 0D6162
40 0H5405
41 0E6193
(1)42 0C6748
(1)43 063617
44 0H1605
45 026902
46 0D2806
47 073590A
48 036949
49 056326
50 0G4413
51 072252
52 058000E
53 0C2262
54 0D3587
55 0E3484
56 0G3259
57 0G4220
58 0G8535
59 0G9651A
60 0G9651B
61 0G9651C
62 0H0497
63 0H1480
64 0H5333B
65 0H5388
66 0H5460
(1) INCLUDED WITH HARNESS
QTY. DESCRIPTION
2 BOLT CARRIAGE 1/4-20 X 1
1 SCREW THUMB 1/4-20 X1/2 W/SHLD
2 RIVET POP .156 X .362 AL
1 ARM EXTENDER PIN CSA
1 BRACKET, ARM EXTENDER
18 NUT HEX LOCK M4-0.7 SS NYL INS
1 RELAY PNL 12VDC DPDT
10A@240VA
1 BLOCK TERM 20A 5 X 6 X 1100V
1 SCREW HHTT #8-32 X 3/8
1 FUSEBLOCK 30A 600V 2POS W/SQ
2 FUSE 5A X BUSS
6 1/4-20 X 1/2" SCREW, PPHM
1 TRIM VINYL BLACK 1/8GP
2 SPACER,200 AMP TRANSFER
SWITCH
1 GROMMET 1.37 X .06 X 1.00
4 NUT TRIC 1/4-20 X .525
1 DECAL TERMINAL STRIP
1 DECAL, FUSE REPLACEMENT
1 DECAL WARN MANUAL OPER
HANDLE
1 DECAL TERMINAL SHOCK HZD BI
1 DECAL, NEUTRAL CONNECTION
1 DECAL,TRANSFER SWITCH ID 200A
1 DECAL, UTILITY SOURCE CONN
1 DECAL, GENERATOR/CUSTOMER
CONN
1 DECAL, UTILITY DISCONNECT
1 DECAL, RTS SERVICE ENTRANCE
TRANSFER SWITCH
1 DECAL TEST SEQUENCE
1 DECAL,XFER SW SE 120/240
1 DECAL LIVE CIRCUIT
2 STANDOFF, HEX M4-0.7 X 10
