1 Introduction
This Manual applies to the following Vetus porthole types:
- PM (PM111 ... PM161, PM111F ... PM16F)
- (PM113 ... PM163)
- PW (PW201 ... PW221, PW20F ... PW22F)
- (PW203 ... PW223)
- PX (PX45F ... PX47F, PXFF, PXFLF)
- (PX45 ... PX47, PXF, PXFL)
- PZ (PZ611 ... PZ671, PZ61F ... PZ67F)
- (PZ613 ... PZ673)
See pages 14, 15 and 16 for Drawings.
2 Safety
Warning: Always keep portholes closed when under way.
3 Fitting
N.B.: The highest permitted design category and the highest permitted application is stated on
every porthole.
When fitting the porthole, take the following into account:
- A porthole must always open inward.
- When fitted in area 1 on sailing or motor ships within design category A or B, no part of the
porthole should protrude beyond the hull.
- Only fit in a completely flat hull section! The porthole will never be watertight when closed if
fitted in a curved surface!
Dust released when cutting and sanding glass-fibre reinforced polyester is hazardous to lungs
and eyes. So always wear a dust mask and goggles when working with this material. Ventilate
the working area well.
The porthole can be fitted in a surface with a minimum thickness of 2 mm. and a maximum thick-
ness of 25 mm.
Draw the hole to be cut out using the porthole frame, for the main dimensions, see page 14, 15.
4
070204.03
W
arning
A I
A III
A I
A III
A I
A III
A I
A III
vetus® Portholes PM, PW, PX, PZ
