OVERVIEW OF THE PROGRAMS
Comfort
Your device's default setting is non-stop Comfort for 7 days a week.
- Comfort: the controller will operate in Comfort mode, 24 hours a day, as regards each day selected.
- Eco: the controller will operate 24 hours a day in Eco mode.
Note: You can set the temperature-lowering parameters, installer settings 1.1
Heat room at different moments every day: Manual change between comfort & eco temperature. The radiator remains
set at the last selected mode (comfort / eco).
WEEKLY PROGRAMS: P1/P2/P3
Heat room at fixed moments every day: Automatic change between comfort & eco temperature.
- P1: the controller will operate in Comfort mode for 1 time block eg: from 06:00 to 22:00 (and in Eco mode from
22:00 to 06:00).
Set comfort temperature 20°
Eco temperature 16,5°
- P2: the controller will operate in Comfort mode for 2 time blocks eg: from 06:00 to 10:00 and from 16:00 to 22:00
(and in Eco mode from 10:00 to 16:00 and from 22:00 to 06:00).
Set comfort temperature 20°
Eco temperature 16,5°
- P3: the controller will operate in Comfort mode for 3 time blocks eg: from 06:00 to 10:00, from 12:00 to 14:00 and
from 18:00 to 22:00 (and in Eco mode from 22:00 to 06:00, from 10:00 to 12:00 and from 14:00 to 18:00).
Set comfort temperature 20°
Eco temperature 16,5°
Note: If the standard times of P1, P2 and P3 do not suit you, you can change them, but then this time applies to
all days of the week on which P1, P2 or P3 is set.
For P2 & P3 there must always be at least 1 hour between the time periods.
Eco P1
0h 2h 4h
0h 2h 4h
0h 2h 4h
P2
6h 8h 10h 12h 14h
6h 8h 10h 12h 14h
6h 8h 10h 12h 14h
P3
16h 18h 20h 22h 24h
16h 18h 20h 22h 24h
16h 18h 20h 22h 24h
09
EN
