Figure 5
Figure 6
Figure 7
Figure 8
100%
100%
WARNING! It is essential for safety that if any part of the PRD is found to be
faulty, or you are in any doubt concerning the safety or condition of the PRD,
100%
it must be removed from service and referred to Latchways or authorized
agent. It may not be used again until confirmed in writing by a competent
300
kg
person that it is safe to do so.
100%
6.1.2 Harness
Refer to harness harness user instruction for inspection and maintenance of the full body harness.
WARNING! Each harness is designed to arrest a fall from height only
• Buckles must be free from rust, excessive wear, distortions or cracks.
once. If subjected to an arrested fall the harness must be immediately with-
drawn from service and destroyed to ensure that it is not used again.
300
kg
• Inspect descent line for any 'slack' between the drum and rack (See Figure 5).
If line shows any sign of slack - the PRD should be removed from service and
refer to Latchways or authorized agent.
• Check the legibility of the product markings.
• Inspect the release pin for signs of damage, distortion, corrosion or cracking.
Ensure that it has not been disengaged. Ensure that the red release cord is
positioned under the release pin and that the load-line webbing is looped around
the release pin (See Figure 6).
• Ensure that the green release pin clip is present and undamaged—check for
signs of damage, distortion or cracking (See Figure 6).
• Ensure that the release cord guide is undamaged (See Figure 7).
• Inspect the descent line, load-line and release cord for signs of cuts, abrasion,
fraying, tears, mould, discoloration, chemical attack or excessive build-up of dirt.
Check the stitching for signs of loosening, pulling or cut thread. Excessive build-
up of dirt may prevent the descent line from pulling through the device.
If damage is apparent do not use. Remove the PRD from service and refer
to Latchways or authorized agent.
• After inspection close the zip on the backpack fully.
• Unzip the back panel of the backpack and inspect the harness connector for
signs of damage, distortion, corrosion or cracking. Ensure that the fastening bolt
is secure (See Figure 8). If damage is apparent do not use. Remove the PRD
from service and refer to Latchways.
• Inspect all system components and subsystems according to Latchways'
instructions.
