Personal Rescue Device
CA
User Instruction Manual
WARNING! Incompatible components can lead to connectors
accidentally disengaging.
5.3.4 Harness
The descender device can only be used when fitted to the dorsal attachment of a harness conforming to
CAN / CSA Z259.10 Class A, which has been fitted by the harness manufacturer or authorized agent
under the approval of Latchways plc.
Refer to harness user instruction manual for further information on use and limitations.
The descender device must not be removed from the harness by the user. If harness exchange is required,
the entire PRD assembly must be returned to Latchways or authorized agent.
5.3.5 Combinations
The PRD may be used with combinations of fall arrest equipment. However, attention must be paid to the
compatibility of such items, and considered part of the risk assessment process—incompatible items (such
as inappropriate connectors) may hinder the operation of fall arrest equipment to which they are attached,
resulting in potential injury to the user.

6. Inspection

100%
The Latchways PRD has been specifically designed as a user friendly device, incorporating a range of
features to aid pre-use checks and on-site periodic examination, and wherever possible minimize the need
to return the device to Latchways or authorized agent.
100%
6.1 Pre-use inspection
These are the detailed descent device and harness checks that should be carried out by the user before
each use.
• Thoroughly inspect all equipment and components before each use.
• No repairs, modifications or alterations are to be carried out on the PRD.
6.1.1 Descent device/line
Figure 3
Figure 4
• Inspect the D-ring connector for signs of damage, excessive wear, distortion,
corrosion or cracking.
• Ensure that the descent line is not paid out of the device, this would indicate that
a descent has occurred (See Figure 3). If descent line is paid out do not use.
Remove the PRD from service and refer to Latchways or authorized agent.
• Open the backpack containing the descent device (See Figure 4).
• Inspect the general condition of the descent device for signs of damage or
corrosion. If damage is apparent do not use. Remove the PRD from service and
refer to Latchways or authorized agent.
12
