System Layout NGC-30-CRM
System layout NGC-30-CRM
230 Vac in
L
N
Alarm relay output
AC voltage up to 277 Vac
L
N
230 Vac
Relay drivers
1
1
3
2
8
3
10
4
12
5
6
Pilot relays
Contactor
located on
coils
circuit board
12 Vdc
Power
Supply
230 Vac
contactor power
To contactor coils
(see detail)
NGC-UIT
Touch
Screen
RTDs
NGC-30-CRM
Distribution panel board with
standard circuit breakers
NGC-30-CTM
ø 1
ø 2
ø 3
N
|
nVent.com/RAYCHEM
