11.8 in.
30 cm
Respect the height and dimensions of the hole given in
gures 2 and 3.
in the window in the wooden
pane kickboard of a
French window
4) Fit the wall ange C1 into the hole.
5) Screw the wall mounting accessory C4 into the hose C2
( g. 4) and t it into the wall ange C1 as shown in g. 5.
11.8 in.
30 cm
2
in the wall: you are
recommended to
insulate the section
of wall using suitable
3
insulation
2
4
MAX100 cm
MAX 39 inches
MIN 35 cm
MIN 14 inches
5
Note:
• As special tools are required for installation, we
suggest you have the appliance installed by specialized
personnel.
• Keep the air hoses as short and free of curves as possible
to avoid constrictions.
When the hose C2 is not tted, the hole can be closed with the
ange cap C1.
Air conditioning without installation
You can also set-up in a double-hung window:
1) Place the bracket in the window sill, extend the bracket
fully within the window frame, x the bracket by using the
pin then lower the window onto the bracket. (Should the
window bracket be too large for the window, the plastic
can be cut with a saw by a quali ed professional).
2) Fit the air exhaust hose in the housing at the back of the
appliance. Insert it as shown in g. 1.
3) Screw the window outlet C7 to the other end of the exhaust
hose (see g. 6).
• If you have a casement window follow steps 2 & 3 and place
the window outlet outside the window to exhaust the hot
air ( g. 9).
6
4) Insert the window outlet
end of the exhaust hose
into the slot of the window
bracket ( g. 7).
Other set-up methods:
• Thanks to the locking pins,
it's possible to use the win-
dow bracket also for sliding
windows. Position the hole
of the bracket so to allow
7
a correct installation of the
exhaust hose (see g. 8).
6
