| Location of Controls |
n
Number Designation Reference Page
© Sound virtualizer button (S.VIRTUALIZER) ....... 17
@) Preset equalizer button (PRESET EQ) ........... 17
@ Display panel
@ Recording timer programming button
(REC TIMER) suis inusmenensatideseesuad ete 26
© Play timer programming button
(PLAY TIMER A, Blues under 24
Timer time adjustment button
(TIMER ADJUST) .......................... 24, 26
@ Clock time adjustment button
(CLOCK ADJUST) .......................,.... 9
Power/battery life check indicator
(POWERIBATT) mul pte xeweatesuee es 5
@ POWER Switch .......................,...... 5
Volume control buttons (VOLUME +, —)
@ Top panel open/close buttons
(TOP PANEL OPEN A, CLOSE FY) .............. 8
@ Remote control signal sensor (SENSOR) ........ 8
@ Speaker
Button © (—/ i, +/>>) functions change according to
the operation mode when pressed.
Time adjustment Setting time Er
Cassette deck controls 5
Number Designation Reference Page
@ Tape edit button (TAPE EDIT) .................. 22
@ Record/record pause button
(@/@ 11 REC/REC PAUSE) ..................... 19
Deck 1
@ Deck 1 eject button (4 DECK 1)
@ Deck1/2 select button (DECK 1/2) ............... 10
Cassette play/direction button (<4 > PLAY/DIR)...10
@ Deck 2 eject button (4 DECK 2) ................ 10
& Deck 2
