Atlas Copco G2414-S085 Consignes D'utilisation Et De Sécurité page 159

G2414-S085
Ref. No. Ordering No.
1(2-3) 4150 1049 83
2 -
3 -
4 4150 1250 03
5(6-7) 4150 1241 90
6 -
7 -
Signs and stickers
Stickers
WARNING WARNING WARNING WARNING
Ref. No. Ordering No.
1 4150 1984 00
1 4150 1985 00
1 4150 1986 00
1 4150 1988 00
Service Kits
Seal kit — Motor casing / Motor / Front part
Ordering No. 4081 0266 90
Ordering No. Qty Description
- 1 O-ring
- 1 Sealing
- 1 O-ring
- 1 O-ring
- 2 O-ring
- 1 O-ring
- 1 O-ring
- 2 O-ring
- 2 O-ring
- 1 O-ring
- 1 O-ring
Service kits are designed for a variety of products. This Service kit may contain more parts than listed in the
table and parts might remain unused.
Service kit — Motor casing / Motor
Ordering No. 4081 0265 90
Ordering No. Qty Description
- 1 Pin
- 1 Pin
- 1 Spacer
- 1 Pin
- 4 Screw
- 1 Ring
Qty Description
1 Collet set
1 Collet
1 Ring
1 Holder
1 Damping kit
1 Cover, compl.
1 O-ring
1
Qty Description
1 Sticker
1 Sticker
1 Sticker
1 Sticker
Remark / Included in Service kit
39.5x2.4
3x1
15.3x2.4
18.1x1.6
29.1x1.6
26.1x1.2
3.3x2.4
12.1x1.6
17.1x1.6
29.2x3
Remark / Included in Service kit
2.5x30
FRP 2x5
FRP 2x5
MFTS M3x6 8.8
© Atlas Copco Industrial Technique AB - 9836 3959 00
EN
Remark / Included in Service kit
6 mm
29.2x3 / Seal kit 4081 0266 90
Remark / Included in Service kit
Text on the sticker: To reduce risk of injury read and understand safety instructions
supplied with tool
Text on the sticker: To avoid injury use recommended guard
RPM rating on wheel must exceed grinder RPM rating
Text on the sticker: Do not remove guard
Text on the sticker: For internal grinding only
RPM rating on wheel must exceed grinder RPM rating
Spare part list
159
