5. Overview

8 9

6. Installation

Remove all packing materials from the TBox G2. Check if ali foam and plastic padding is remo-
ved. Connect ali cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
User Manual - [T]Box G2
1. LCD display
2. Jog wheel
3. 9V DC power adapter IN
4. Voltage warning LED indicators
1
5. Micro SD slot
6. Power LED indicator
7. Power switch ON/OFF
2
8. 5-pin DMX/RDM signal connector OUT
9. 5-pin DMX/RDM signal connector IN
10. MIDI IN
10 3 4
35 C
Under Voltage
5 6 7
