Changing the battery/Technical Data
Changing the battery
Maintenance
Clean the device with a damp cloth only. Do not use a cleansing agent
since this could damage the plastic.
Technical data
Nominal voltage:
Switched current:
Battery type:
System of protection:
Protection class:
Permissible
ambient temperature:
Type of installation:
Subject to technical modifications.
General conformity declaration
The company SELVE GmbH & CO. KG, hereby declares that the
i-Timer Plus is in conformity with the basic requirements and other
relevant provisions of the Directive 1999/5/EC.
1. Disconnect the operating device.
2. Remove the battery.
3. Insert the new battery properly
(CR 2032).
4. Reset the time.
Note: The values set are still saved.
230–240 V AC/50–60 Hz
5 A/250 V AC for cos φ = 1
CR 2032
IP 20
II
0 to +55 °C
Concealed Ø 58 mm wall-mounted,
exposed in appropriate exposed casing
