c) Tyre Change
• Front axle
There are two ball bearings on the front axle:
one on the outside of the rim (1) and one on the
inside (2).
When changing the tyres, make sure to remove
the ball bearings from the rim and insert them in
the new rim.
Also make sure that the spacer sleeve (3) is
properly positioned.
• Rear axle
When changing the tyres on the rear axle, make
sure you do not lose the driving pin (1) in the
wheel axle (2) or the spacer (3).
Also make sure that the driving pin is positioned
exactly in the designated hole (4) when you at-
tach and screw tight the rim.
Otherwise the driving pin cannot properly trans-
mit the driving force to the rim and the rim will
be damaged.
All manuals and user guides at all-guides.com
3
1
4
2
3
2
1
55
