English
WARNING:
Everyday eyeglasses are NOT safety glasses. Also use face or
dust mask if operation is dusty. ALWAYS WEAR CERTIFIED
SAFETY EQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratory protection.
WARNING:
chemicals known to State of California to cause cancer, birth
defects or other reproductive harm. Some examples of these
chemicals are:
• compounds in fertilizers,
• compounds in insecticides, herbicides and pesticides,
• arsenic and chromium from chemically treated lumber.
To reduce your exposure to these chemicals, wear approved
safety equipment such as dust masks that are specially
designed to filter out microscopic particles.
• Avoid prolonged contact with dust from power
sanding, sawing, grinding, drilling, and other
construction activities. Wear protective clothing and
wash exposed areas with soap and water. Allowing dust
to get into your mouth, eyes, or lay on the skin may promote
absorption of harmful chemicals.
WARNING:
generate and/or disperse dust, which may cause serious and
permanent respiratory or other injury. Always use NIOSH/
OSHA approved respiratory protection appropriate for the
dust exposure. Direct particles away from face and body.
WARNING:
personal hearing protection that conforms to ANSI
S12.6 (S3.19) during use. Under some conditions and
duration of use, noise from this product may contribute to
hearing loss.
CAUTION:
on its side on a stable surface where it will not cause a
tripping or falling hazard. Some tools with a large battery
pack will stand upright but may be easily knocked over.
• Air vents often cover moving parts and should be
avoided. Loose clothes, jewelry or long hair can be caught in
moving parts.
The label on your tool may include the following symbols. The
symbols and their definitions are as follows:
V ......................... volts
Hz ....................... hertz
min ..................... minutes
or DC ...... direct current
...................... Class I Construction
(grounded)
.../min .............. per minute
BPM .................... beats per minute
IPM ..................... impacts per minute
RPM .................... revolutions per
minute
sfpm ................... surface feet per
minute
6
ALWAYS use safety glasses.
Some dust contains
Use of this tool can
Always wear proper
When not in use, place tool
SPM .................... strokes per minute
OPM .................... oscillations per
minute
A ......................... amperes
W ........................ watts
or AC ........... alternating current
or AC/DC .... alternating or
direct current
...................... Class II
Construction
(double insulated)
n o ....................... no load speed
n ......................... rated speed
...................... earthing terminal
..................... safety alert symbol
..................... visible radiation
..................... avoid staring at
light
..................... wear respiratory
protection
ASSEMBLY AND ADJUSTMENTS
WARNING:
serious personal injury, turn unit off and remove
the battery pack before making any adjustments or
removing/installing attachments or accessories, when
replacing line, or prior to cleaning. An accidental start-up
can cause injury.
Attaching Guard (Fig. B, C)
WARNING:
Damage or personal injury could result.
WARNING:
APPLIANCE WITHOUT GUARD FIRMLY IN PLACE. The
guard must always be properly attached on the appliance to
protect the user.
1. Remove the guard screw
2. Slide the guard
11
fully onto the trimmer head
Make sure the tabs
17
on the guard engage the ribs on the
trimmer head.
3. Continue to slide the guard on until it "snaps" into place.
The locking tab should snap into the housing slot.
4. Using a crosshead screwdriver, insert the guard screw
and tighten securely.
5. Once the guard is installed, remove the covering from
the line cut-off blade, located on the edge of the guard.
Attaching the Auxiliary Handle (Fig. D)
For some models the auxiliary handle may need to be
attached. If the model needs the auxiliary handle attached,
please refer to these instructions.
1. To attach the auxiliary handle
handle adjustment buttons
housing as shown in Figure D.
2. Position the auxiliary handle as shown in Figure D.
Partially push the auxiliary handle on so it will hold the
buttons in when you release them with your hand.
3. Push the auxiliary handle completely onto the housing
and position it slightly until it "snaps" into place.
nOTE: To adjust the auxiliary handle up or down, press in
on the buttons and raise or lower the handle.
nOTE: The handle should be adjusted so that your front
arm is straight when the trimmer is in the working position.
Height Adjustment (Fig. E)
CAUTION:
to obtain proper working positions.
1. The overall height of the trimmer can be adjusted by
loosening the height-adjust collar
direction of the arrow shown in Figure E.
2. Move the upper housing straight up or down. When the
desired height is achieved, tighten the collar by rotating it
opposite of the direction shown in Figure E.
..................... wear eye
protection
..................... wear hearing
protection
..................... read all
documentation
IPXX .................... IP symbol
To reduce the risk of
Never remove the guard.
NEVER OPERATE
16
.
8
, press in on the auxiliary
5
15
on both sides of the upper
Adjust the length of the trimmer
6
by rotating it in the
.
