STEP 2: REAR WHEELS
1.
Remove all hardware from the axle.
2.
Install the wheel with stem facing out, then large washer, then nut. Turn by hand to tighten,
back off nut to align hole, insert the pin and secure as shown.
3.
Align the wheel cap in the groove and tap lightly with a rubber mallet or a block of wood and
hammer until seated evenly into the groove.
NOTE: Your chipper tires are D.O.T. approved, but only for street towing. This unit is not build
for highway towing. Tires are rated for 45 mph (72 km/h).
ASSEMBLY STEPS AS SHOWN
1.
Install wheel with valve stem on the outside
Washer
2.
3.
Nut
4.
Pin
1
5.
Cap
2
All manuals and user guides at all-guides.com
STEP BY STEP INSTRUCTIONS
3
4
ASSEMBLY
5
v.210818 | 5
