PARTS & SCHEMATICS
PARTS LIST
No.
Specification
1
Feed hopper
2
Outlet hopper
3
Support foot
4
Tow bar connecting part
5
Wheel axle
6
Crush house
7
Tool box cover
8
M8 locknut
9
Dia. 8 lockwasher
10
Washer dia. 8 x dia. 16 x 1.6
11
Plate for protection sheet
12
Protection sheet
13
Hexagon headed bolt M8 x 25
14
Key switch
15
Pipe plug
16
Wire
17
Belt
18
Spacer sleeve dia. 9 x dia. 14 x 44
19
Belt cover accessory plate
20
Bolt M8 x 60
21
Engine pulley
22
Washer dia. 10 x dia. 40 x 3.0
23
Bolt 3/8-24 UNF-25
24
Belt cover
25
Bolt M8 x 16
26
Bolt M10 x 25
27
Washer dia. 10 x dia. 40 x 3.0
28
Rotor pulley
29
M10 locknut
30
Dia. 10 lockwasher
31
Spacer sleeve dia. 11 x dia. 20 x 17
32
Key
33
Mounted bearings
34
Steel plate for mounted bearing
35
Rotor
36
Blade
37
Blade bolt
18 | OPC506(G) man.
All manuals and user guides at all-guides.com
No.
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
Specification
Hexagonal slotted thin nut M24 x 1.5
Washer dia. 25 x dia. 47.5 x 3.0
D.O.T. Tire
Pin dia. 4.0 x 40
Bolt M10 x 80
Washer dia. 10 x dia. 22 x 2.2
Rubber
Bolt M8 x 65
Buckle
Chain
Bolt M10 x 90
Tow bar
Hitch trailer
Square latch
M10 knob
Blade gap adjusting plate
Feeding helper plate
Engine wire
Engine plate
Key
Spacer sleeve dia. 26 x dia. 35 x 15
Engine
Knob
Outlet hopper adjusting plate
Upper part of outlet hopper
Bolt M6 x 16
Dia. 6 lockwasher
Clip
Bearing cap
B-shaft ring dia. 30
Inside hexagonal cylindrical head screw M6 x 90
M6 locknut
Bolt M5 x 16
Clip
Washer dia. 5 x dia. 10 x 1.0
Dia. 5 lockwasher
M5 locknut
