Analogue speed/start signal (pin 5)
Voltage range
Stop (zero motion hold)
Speed
Max. speed
The conveyor speed results from the gear ratio and the voltage rating of the analogue speed signal.
3.11

RollerDrive connector BI

Pin Colour
1 Brown
2 White
3 Blue
4 Black
5 Grey
NOTE
Connecting/disconnecting under voltage can destroy the RollerDrive EC5000 with bus interface
¾ The RollerDrive EC5000 BI is not hot-plug-compatible. Disconnect the power supply to connect/disconnect
the RollerDrive EC5000 BI.
Version 2.5 (04/2020) UL
Translation of the original operating manual
Function
Input of the power supply
(+)
CAN High
Earth for power supply and
signal (-)
CAN Low
Service manufacturer
Product information
0 to 24 V DC
0 to 2.3 V DC
2.3 V DC to 10 V DC
2.3 V = Minimum speed = 300 rpm
10 V = Maximum speed = 6900 rpm
10 V DC to 24 V DC
Value
Rated voltage:
Voltage range:
Earth
24 V DC 48 V DC
18 to 28 V DC 36 to 56 V DC
