Scope Of Delivery; Recommended Accessories; General Description - ROBBE PROFI Notice D'utilisation

1.

SCOPE OF DELIVERY

1.1

RECOMMENDED ACCESSORIES

2.

GENERAL DESCRIPTION

The Profi Homecharger is an intelligent home charging station
with easy battery management for charging and discharging of
NC, NiMH, lead and lithium batteries.
The reflex charge procedure already prevents undesirable
memory and lazy battery effects with NC and NiMH batteries
during the charging process.
The mains-powered device has four programmable charging
outputs which are independent of each other and which are
executed one after the other. This means that both the same
as well as different battery types and charge programs can be
selected. The Profi Homecharger is equipped with an automa-
tic start function; when a battery is plugged in charging starts
automatically.
If a process is finished or a battery is removed, then the soft-
ware ensures that the next charge Output with connected bat-
tery is executed.
The menu is controlled via the large background lit 2 x 16 cha-
racter dot-matrix LC display. Once it has started, you will be
informed about all necessary parameters of the current char-
ging procedure in the "working" display. The charge current,
charge voltage, charged or discharged capacity and the char-
ged or discharged time elapsed are displayed.
The charge and discharge current are automatically detected
in automatic mode for NC and NiMH batteries and set to the
optimum value by the software.
This ensures that the batteries are charged carefully and
quickly. The end of the charge program is signalled optically
and acoustically.
Profi-Home-Charger
Transmitter battery char-
ge cable No. F 1415
The Profi Homecharger is one of the first home stations which
can safely charge or discharge not only conventional and
modern batteries but also high capacity batteries such as
lithium-ion and lithium polymer batteries.
Different charging and discharging programs are ready to opti-
mally supply the different lithium battery types.
Particular attention was paid to the disconnect voltage with
regard to this; both charging/discharging are determined very
precisely so that the charge/discharge currents are discon-
nected at exactly the right moment.
The Profi Homecharger software has seven different charging
programs, depending on the type of battery.
NC + Lead +
Charge program
NIMH Lithium
• -
Charging in automatic mode
• •
Charging in manual mode
• -
Discharge-charge in automatic mode
• •
Discharge-charge in manual mode
• -
Discharge-charge in auto. mode with 3 cycles
• -
Discharge-charge in man. mode with 3 cycles
Regeneration program, with discharging and
• •
subsequent C/5-charging, depending on the
pre-selected battery capacity
This means that nearly all charge types that occur in practice
are covered.
17
Order No.
8194
The scope of delivery con-
sists of the Profi
Homecharger with plug-in
supply cable.
Receiver battery charge cable
No. F 1416
