3. INSTALLATION INSTRUCTIONS
BEFORE USING YOUR APPLIANCE
Remove the exterior and interior packing.
•
Before connecting the appliance to the power source, let it stand upright for approximately 4 hours. This will
•
reduce the possibility of a malfunction in the cooling system from improper handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
•
INSTALLATION SPECIFICATIONS
This appliance requires a standard 115 Volt A.C. /50Hz electrical outlet with three-prong ground
•
This appliance is designed to be installed built-in or free standing.
•
Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct
•
sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Ambient
temperature below 68° F (20°C) or above 90° F (32°C) will hinder the performance of this appliance. This
unit is not designed for use in a garage or any other outside installation.
Avoid locating the appliance in moist areas.
•
Plug the appliance into dedicated, properly installed-grounded wall outlet. Do not under any circumstances
•
cut or remove the third (ground) prong from the power cord. Any questions concerning power and/or
grounding should be directed toward a certified electrician or an authorized service center. This unit is not
designed to be installed in an RV or used with an inverter.
After plugging the appliance into a wall outlet, allow the unit to cool down for 3 ~ 4 hours before placing
•
wine bottles or beverage cans in the appliance.
This wine cooler come with adjustable legs (in the front) to help level the unit
•
BUILT-IN INSTALLATION
The cutout dimension illustrated in figure (A) allows for door swing and access to the pull-out shelves when
installed as a built-in appliance. If installing between frameless cabinets, a ½" wide filler strip or side panel may
be needed on hinge side. The filler strip will act as a spacer between the appliance case and adjacent cabinet
door swing. The width of the opening must include the filter panels.
Note:
The door should protrude at least 1" beyond the surrounding cabinets.
24 ½" Including door
24 ½" Including handle
21 ¼" (cabinet only)
33 ½"
15"
。
15-3/4"
min.
14
