1. Align the holes in the upper handle and the lower
handle.
2. Put the bolts through the holes.
3. Tighten the knobs onto the bolts.
4. Do the same operation on the other side.
3.4

INSTALL THE GRASS CATCHER

Figure 4.
1. Remove the mulch plug.
2. Remove the side discharge chute.
3. Open the rear discharge door and hold it.
4. Hold the the grass catcher by its handle and engage
the hooks on the door rod.
5. Close the rear discharge door.
3.5

INSTALL THE MULCH PLUG

Figure 5.
1. Remove the grass catcher.
2. Open the rear discharge door and hold it.
3. Hold the mulch plug by its handle and fit it in the
discharge chute.
4. Close the rear discharge door.
3.6 INSTALL THE SIDE DISCHARGE
CHUTE
Figure 6.
CAUTION
When you use the side discharge chute,
• do not install the grass catcher.
• keep the mulch plug installed.
1. Open the side discharge door and hold it.
2. Line up the recesses of the side discharge chute
below the pivot.
3. Close the side discharge door.
3.7

SET THE BLADE HEIGHT

The machine can be set to different blade heights.
Figure 7.
1. Pull the height adjustment lever rearward to
increase the blade height.
2. Pull the height adjustment lever forward to decrease
the blade height.
3.8

INSTALL THE BATTERY PACK

Figure 8.
English
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
The machine has an automatic switch function that
lets the other battery work when the first cannot
operate.
1. Open the battery door.
2. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
3. Push the battery pack into the battery compartment
until the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery door.
The engine starts only when you put in the safety key.
3.9

REMOVE THE BATTERY PACK

Figure 8.
1. Open the battery door.
2. Remove the safety key.
3. Push and hold the battery release button.
4. Remove the battery pack from the machine.
4

OPERATION

Wear eye protection during operation.
4.1

START THE MACHINE

Figure 9.
1. Put in the safety key.
2. Push and hold the start button.
3. While you hold the start button, pull the bail switch in
the direction of the handle bar.
4. Release the start button to start the machine.
Soft-Start
This Li-ion machine has a "soft-start" feature.
When you start the machine, it goes to full speed after
approximately 3 seconds.
5
WARNING
NOTE
NOTE
WARNING
EN
