ASSEMBLY INSTRUCTIONS
9
I
Variable Spray Nozzle Lance installation
Insert variable spray nozzle (I) or detergent bottle (H)
into the end of the extension lance by inserting and
pushing together turning clockwise simultaneously. To
remove push together and turn counterclockwise.
Note: Push the safety lock button to lock the trigger
when changing lances to ensure that they do not
accidentally eject with force during removal.
11
H
Insert detergent bottle (H) into extension lance (J),
push in and turn clockwise
J
J
10
H
Detergent Bottle Installation
The detergent bottle comes with a straw which is fitted
into screw-on top. If you do not see the straw, look
inside the bottle and attach it to the screw-on top. When
using detergent bottle, fill it with a properly formulated
detergent or cleaner with a water ratio according to
instructions on the container.
• Pressure washer detergents are recommended. See
page 13 for more information.
• DO NOT use thick or gel-like detergents as they will
clog the power washer and can cause damage.
12
Garden Hose Adapter Installation
Remove plastic shipping cover on water inlet on back
side of power washer unit (C). Install the clear quick
connect (K) to water inlet by hand, tightening clockwise.
C
K
