Resol DeltaSol CS Plus Manuel page 155

Display channels
Channel Description
INIT x* ODB initialisation active
FLL x* ODB filling time active
STAB x* ODB stabilisation in progress
COL x Temperature collector
TST x Temperature store
S3 x Temperature sensor 3
TSTT x* Temperature store top
S4 x Temperature sensor 4
TFL x* Temperature flow sensor
TR x* Temperature return sensor
VFD x* Temperature Grundfos Direct Sensor™
L/h x* Flow rate Grundfos Direct Sensor™
n % x Speed R1
hP x Operating hours R1
hP1 x* Operating hours R1 (if OBST is activated)
hP2 x* Operating hours R2 (if OBST is activated)
kWh x* Heat quantity in kWh
MWh x* Heat quantity in MWh
TIME x Time
Adjustment channels
Channel Description
Arr x System
DT O x Switch-on temperature difference R1
DT F x Switch-off temperature difference R1
DT S x Set temperature difference R1
RIS x Rise R1
PUM1 x Pump control type R1
nMN x Minimum speed R1
nMX x Maximum speed R1
S MX x Maximum store temperature
OSEM x Store emergency shutdown option
Collector emergency temperature
EM x
Collector emergency temperature if ODB is activated:
OCC x Collector cooling option
CMX x* Maximum collector temperature
OSYC x System cooling option
Connection terminal Page
- 52
- 52
- 52
S1 53
S2 53
S3 53
S3 53
S4 53
S1 / S4 / VFD 53
S4 / VFD 53
VFD 53
VFD 54
R1 54
R1 55
R1 55
R2 55
- 54
- 54
- 55
Factory setting Page
1 55
6.0 K [12.0 °Ra] 56
4.0 K [8.0 °Ra] 56
10.0 K [20.0 °Ra] 56
2 K [4 °Ra] 56
PSOL 57
30 % 57
100 % 57
60 °C [140 °F] 57
OFF 58
130 °C [270 °F] 58
95 °C [200 °F] 58
OFF 58
110 °C [230 °F] 58
OFF 59
11
