Dimplex CAB10A Instructions D'installation Et D'utilisation page 7

Children of less than 3 years should be kept away unless continuously supervised. Children aged
from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been
placed or installed in its intended normal operating position and they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
CAUTION
- Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
WARNING
- This heater is not equipped with a device to control the room temperature.
Do not use this heater in small rooms when they are occupied by persons not capable of leaving
the room, unless constant supervision is provided.
INSPECTION
The frequency of the cleaning schedule is dependent upon the environment the air curtain has
been installed into. As a minimum Dimplex recommend a weekly inspection to ensure that there
is no signifi cant build-up of dust or dirt reducing the performance of the air curtain and causing
nuisance smell. Upon inspection, if any foreign objects are encountered which may cause damage
to the fan, impellors or elements they must be removed.
The external appearance of the air curtain can be maintained by wiping occasionally with a damp
cloth. For stain removal, a weak soap solution can be applied with a cloth and the surface wiped
dry. Care must be taken to avoid any moisture ingress into the product.
1. The inside of the air curtain must be cleaned at a minimum interval of once every 3 months, or
more frequently if the weekly inspection deems it necessary. To clean the product remove the
inlet grills by doing the following:
a. Using a fl at head screwdriver, loosen both outlet grill screws to remove the grill ('x' in Fig. 4)
b. Using a Philips head screwdriver, remove the three M4 screws to remove the bottom panel
('z' in Fig. 4)
c. Locate and remove the two M4 screws located behind the inlet grills on the lower left and
right hand sides (fi xed to the end caps)
d. Rotate and remove the inlet grill to expose the heating elements
2. Once the heater bank has been accessed the unit can be cleaned using a vacuum cleaner with
a brush attachment being careful not to disturb or damage the internal wiring or thermal cut-
outs. When the element bank has been cleaned, the inlet grill must be replaced before the air
curtain is turned back on.
3. Please note that the motors do not require any additional lubrication.
WARNING: IN ORDER TO AVOID OVERHEATING DO
NOT COVER.
7
