ACCESSORIES -

R
ADIO TRANSMITTER SUN
SUN 2CH code ACG6052
SUN CLONE 2CH code ACG6056
C
ODE LEARNIG SYSTEM RADIORECEIVERS
RX91/A quarzata and coupling
RX91/A quarzata and terminal board
RX433/A super eterodyne and coupling
RX433/A super eterodyne and terminal board
RX433/A 2CH super eterodyne, 2 channel and coupling code ACG5051
RX433/A 2CH super eterodyne, 2 channel and terminal board
S
PARK
In order to make the systems mentioned above give the best
performances, you need to install an antenna tuned on the frequency
of the radio receiver installed.
N.B. Pay attention to not let the central wire of the cable to came
Into contact with the external copper sheath, since this would
prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can
reach it.
SPARK BLINKER WITH IN-BUILT INTERMITTENT CARD
LATERAL SUPPORT
SPARK ANTENNA 91
SPARK ANTENNA 433
For the connections and the technical data of the optional equipments follow the relevant
handbooks.
SUN 4CH code ACG6054
SUN CLONE 4CH code ACG6058
code ACG5005
code ACG5004
code ACG5055
code ACG5056
code ACG5052
code ACG7059
code ACG7042
code ACG5454
code ACG5452
F
IT SYNCRO
FIT SYNCRO PHOTOCELLS for the wall-installation
The range you can set is 10-20 m, 30÷60ft.
You can fit many couples close together thanks to the synchronising
circuit.
Add the SYNCRO TRANSMITTER
for more than 2 photocells couples (up to 4).
COUPLE OF BUILT-IN BOXES FOR THE FIT SYNCRO
E
LECTRIC LOCK
Horizontal lock - right external view - 12Vac
Horizontal lock - left external view - 12Vac
Vertical lock - 12Vac
M
ECHANICAL BOLT
Mechanical bolt suitable for 2 leaves gate to latch closed the gate to the
ground.
33
33
G
B
code ACG8026
code ACG8028
code ACG8051
code ACG8660
code ACG8670
code ACG8650
