2.1. UNIT ASSEMBLY

Rubber hinge
X2
Wall screw
X4
1. Without opening the unit cover, screw the 4 suspension eyes to the box from behind.
2. Place the unit against the wall and mark the position of the 4 eyes.
3. Drill and insert the 4 rawlplugs into the wall.
4. Screw in the 4 wall screws and hang up the unit.
2.2. PH and REDOX CHIP ASSEMBLY
USE ONLY GENUINE REPLACEMENT PARTS
AquaRite Flo Advanced
Rubber stopper Rawlplug
for hinges X2
Suspension eye Screw for suspension eye
X4
X4
X4
