TLS2 Setup

[249-252] Comm Port Setup Screen 2

Legend for numbered boxes
This screen concludes the Comm Port setup.
1
Baud Rate [249]- touch the Down Arrow button to the
right of the window and select a desired baud rate: 300,
600, 1200, 2400, 4800, or 9600 (default).
2
Parity [250] - touch the Down Arrow button to the right
of the window and select a parity: None, Odd (default),
or Even.
3
Data Length [251] - touch the Down Arrow button to the
right of the window and select a data length: 7 (default)
or 8 .
4
Stop Bits [252] - touch the Down Arrow button to the
right of the window and select the number of stop bits:
1 (default) or 2.
01-01-2000 ALL FUNCTIONS NORMAL
12:00 AM
SYSTEM SETUP COMMUNICATIONS
1
[249]
2
[250]
3
[251]
4
[252]
[249-252] Comm Port Setup Screen 2
COMM 1
9600
ODD
7
27
