Unpacking the Product

After unpacking the product, inspect it for damage that may have
occurred in transit. If it has been damaged, do not attempt to install
or operate it. File a claim immediately with the carrier, stating the
extent of damage. Carefully check all envelopes, shipping labels,
and tags before removing or destroying them. Ensure that the
parts listed in Table 2.
Qty. Description
1 Speaker, 6.5", two-way, high fidelity
1 Steel backbox with mounting screws and speed nuts
1 Tile bridge, galvanized steel
Speaker amplifier sold separately. 2 x 14 to 18 AWG wire required for
speaker connections.

Selecting Power Tap Settings for Model AMR6-2570

Model AMR6-2570, the 25/70 volt model, is factory configured for
70 Vrms, 8 watt operation. To change the setting, move the power-
tap wire from the 70 V, 8 W tap setting (Transformer TAP-4) to one
of the voltage and output level settings as shown in Table 3. For
example, for 70 V, 4 W operation, move the power-tap wire from
TAP-4 to TAP-5. For 25 V, 8 W operation, move the power-tap wire
from TAP-4 to TAP-1.

Table 3. Power tap settings for Model AMR6-2570

Watt
0.5
1
2
4
8
Models AMR6-2570K and AMR6-100K

Table 2. Speaker kit contents

Transformer Power Tap
25 V BLK (COM)
TAP-5
TAP-4
TAP-3
TAP-2
TAP-1
70 V BLK (COM)
TAP-8
TAP-7
TAP-6
TAP-5
TAP-4
3
