6
Models AMR6-2570K and AMR6-100K
Wiring the Speaker
SHOCK HAZARD
To avoid electrical shock, do not connect this speaker to the
system wiring when the circuits are energized.
Failure to heed this warning may result in personal injury or
death.
WIRING PRECAUTION
All wires going through holes should be protected by a grom-
met or convolute/split-loom tubing.
Wire the speaker in accordance with local codes.
1.
Strip 1/4 inch of the insulation from 2 x 14–18 AWG wires.
2.
Connect the field wires to the corresponding speaker termi-
nals (AUDIO – and AUDIO +).
3.
Connect the field wires to a signal source that corresponds to
the voltage and output tap settings of the speakers: 25 Vrms,
70 Vrms, or 100 Vrms
4.
To connect speakers in parallel, see Figure 2 on page 7.
Testing the Speaker
SOUND HAZARD
All effective warning speakers produce loud sounds, which
may cause in certain situations, permanent hearing loss. You
should take appropriate precautions such as wearing hearing
protection.
After installation, test the sound system to ensure proper operation.
