Intermediate Position - Selve commeo Multi Send BASIS Notice

General section (BASIS and PREMIUM)

12.7. Intermediate position 1

The intermediate position is a freely selectable position between the upper and lower end
positions.
Setting intermediate position 1:
Operation
>3 s
Move to intermediate position 1:
Operation
x2
Movement
Move the drive to the upper end position by pressing
the UP button.
Press and hold the STOP button, then also press and
hold the DOWN button. Continue to hold both buttons.
The programming run begins after 3 seconds. Keep the
STOP button held down and use the UP and DOWN
buttons to set the required intermediate position 1.
Release the STOP button to save the position.
Movement
Press the DOWN button twice in quick succession
(double press).
91
EN
