Programming; Position Display" Start Screen; Automatic Mode - Manual Mode - Selve commeo Multi Send BASIS Notice

BASIS version

14. Programming

14.1. "Position display" start screen

No devices assigned
No devices are assigned to the commeo
Multi Send when it is first delivered or fol-
lowing a factory reset.
You can access the main menu.
In this state, the drives and receivers must
first be assigned in the commeo Multi Send.
14.1.1. Automatic mode – manual mode
At least 1 device assigned
Use the left display button
switch from the start screen to the main
menu.
The display of the left display button
depends on whether the sensor visualisation
is activated or deactivated.
: Sensor visualisation deactivated
: Sensor visualisation activated
Use the right display button
switch between automatic and manual
mode.
Use the right display button to switch
between automatic and manual mode.
Press = switch to manual mode
Press = switch to automatic mode
95
or to
or to
EN
