Installation Steps

Attach fasteners to the (2) outboard hoodshield shield flanges by inserting screw with
washer through the hood shield, and into well nut. Partially thread screw into well nut.
3
Expose 2" (5 cm) of tape liner from each end of the center flanges on the hood shield. Ensure that free
4
Center part on front edge of hood and align holes.
5
With the fastener assembly inserted into hole in
hood, secure hood shield to hood by tightening
screw to expand well nut. Repeat for remaining
7
NOTE: DO NOT OVER TIGHTEN
NOTE: Actual application may vary slightly from illustrations.
ends are accessible.
fastener.
NOTE: Observe the alignment from the side view in
order to guide the hood shield with its attached fastener
into the proper hole in the hood.
Hood
Hood
shield
6
Note the (2) inboard hole locations.
8
Page 2 of 3
Screw
Washer
Hood shield
Well nut
free end
Well Nut
Screw and
Washer
