AVS Bugflector Instructions D'installation

Bugflector
For proper installation and best possible fit, please read all instructions BEFORE you begin.
For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219.
Important Safety Information
• CAUTION - Before driving, ensure that the hood shield is properly secured to vehicle.
• Do not use automatic "brush-style" car washes.
• Do not use cleaning solvents of any kind.
• Periodically check all components for tightness.
Contents
NOTE: Actual product may vary from illustration.
Tools Required
Car Wash Supplies
Preparation Before Painting / Installation
• A trial fit is recommended to ensure proper positioning and fit.
• Check fit of parts before painting as we will not accept the return of modified or painted parts.
• Wash and dry your vehicle to remove any debris and/or dirt from the installation area.
Installation Steps
Open hood and locate the hood latch assembly, behind
1
Installation Instructions
- Bugflector II
®
Hood shield
Clean Towel Phillips Screwdriver
NOTE: Actual application may vary slightly from illustrations.
the front grill.
- Carflector
®
Bump On x4 Screw x2
10 mm
Socket Wrench
Disconnect the latch assembly from the hood by
2
Page 1 of 3
I - Sheet Number BF33 Rev.B
®
Washer x2
Wrench
removing (2) screws with wrench.
Well Nut x2
