8.
Repeat installation process for each additional
rail assembly.
III. FIELD CUT ANGLE BRACKET
1. Slide handrail bracket over ends of railing.
Measure angle required, cut bracket and rail
(and aluminum channel) to that angle.
2. Repeat for bottom rail.
3. Install railing per instructions for level railing.
NOTE: The maximum cut angle should be
no greater than 21.5 degrees to ensure the
bracket/rail does not overhang the 4x4 post. If
you use this bracket at an angle greater than
21.5 degrees, it is recommended to use a
larger post sleeve.
You will want to cut the angle bracket enough
to keep your spacing between your post and
first baluster at a minimum (4" or less).
Depending on how much the bracket has been
cut, a shorter screw may be necessary (to
ensure screw does not protrude through the
post sleeve).
Finished Installation
Fig. 10
Fig. 11
