7.
a. For each installed bracket, pre-drill in the
center of each elongated hole with a
bit (Fig. 15).
b. Install #10 x 1" screws in all pre-drilled holes
(Fig. 16).
c. Match letter on inside of bracket cover to the
letter on bracket, and snap cover in place.
Repeat for all brackets (Fig. 17).
8.
INSTALL THE SUPPORT FOOT COVER
a. Attach the support foot to the deck surface
using support foot screw and snap the cover
into place (10' only) (Fig. 18).
6
⁄
" drill
1
8
Fig. 15
Fig. 17
Fig. 13
Fig. 14
Fig. 16
Fig. 18
