5
6
7
8
9
10
11
12
13
14
15
4.3.

Radio rate selection

The radio rate is determined by the S254 register.
Register S254
0
1
2
4.4.

Power output

The RF output power is selected by the S231 register. There is 4 RF output power available, 500mW, 1W, 2W
and 4W.
Register S231
0
1
2
3
After a long use at 4W, the radiator and the box can warm until 65°C without spoiling the working.
4.5.

RSSI reading

The RSSI (Received Strength Signal Indicator) gives an indication for the received power level of the last
demodulated frame. It is available in S230 register. This level must be used with care due to dispersion between
components.The RSSI can also be added at the beginning of each incoming frame. The RSSI value is coded on
one byte. This byte codes the absolute value of the RSSI with a maximum at -70dBm.
Register S300
2
5.

Modem operating mode

Three operating modes are available:
• Commandmodeformodemsetup
UG_ARF73 V1.7
All manuals and user guides at all-guides.com
S238 – 150kHz
S238 – 100kHz
S238 – 50kHz
S238 frequency (central frequency calibrated in factory process)
S238 + 50kHz
S238 + 100kHz
S238 + 150kHz
S238 + 200kHz
S238 + 250kHz
S238 + 300kHz
S238 + 350kHz
RF link speed (bps)
Not available
4800
9600
RF output
0.5W - 27dBm
1W – 30dBm
2W – 33dBm
4W – 36dBm
RSSI
Append RSSI at the beginning of frame
24
