ELECTRICAL / GAS CONNECTIONS

RECOMMENDED GROUNDING METHOD

This appliance is factory equipped with a power supply cord with a four-prong grounding plug. It
must be plugged into a mating grounding, type receptacle, connected to a correctly polarized 120/240
volt circuit. If the circuit does not have a grounding type receptacle, it is the responsibility and
obligation of the installer to have the existing receptacle changed to a properly grounded and
polarized receptacle in accordance with all applicable local codes and ordinances by a qualified
electrician. In the absence of local codes and ordinances, the receptacle replacement shall be in
accordance with the National Electrical Code.
THE FOURTH PRONG (ROUND GROUNDING PIN) SHOULD NOT, UNDER ANY
CIRCUMSTANCES, BE CUT OR REMOVED.

GAS REQUIREMENTS

Verify the type of gas supplied to the location. The range is shipped from the factory set up and
adjusted for natural gas. It can be field-converted for LP (propane) gas. Refer to instructions included
with the conversion kit that is packed with the unit.

NATURAL GAS

Connection: 1/2" N.P.T. Minimum 5/8" dia. flex line.
LP GAS
Connection: 1/2" N.P.T. Minimum 5/8 dia. flex line.
A regulator is required at the LP source to provide a maximum of 14"W.C. to the range regulator.

HOOK-UP TO GAS SUPPLY

HOOK-UP
A manual valve must be installed external to the appliance, in an accessible location from the front for
the purpose of shutting off the gas supply. The supply line must not protrude beyond the back of the
unit. Make sure the gas supply is turned off at the wall valve before connecting the appliance.
The gas supply connections should be made by a qualified technician and in accordance with local
codes or ordinances. In the absence of a local code, the installation must conform to the National Fuel
Gas Code ANSI 223.1-1988, latest edition.
Supply Pressure: 6" to 14"W.C.
Supply Pressure: 11" to 14"W.C.
13
