English
Specifications
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
A = 300 hours
B = 125 hours
C = 50 hours
Engine
Single cylinder two-stroke engine
Displacement: 35.2 cm
Bore: 40 mm
Stroke: 28 mm
Engine power to 1.8 kW (2.4 HP)
ISO 7293: at 9,500 rpm
Idle speed: 3,000 rpm
High speed setting
when performing
repairs (with bar and
chain): 14,000 rpm
Ignition System
Electronic (breakerless) magneto
ignition
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.5 mm
38
This spark ignition system meets all
requrements of the Canadian
Interference-Causing Equipment
Regulations ICES-002.
Fuel System
All position diaphragm carburetor with
integral fuel pump
Fuel tank capacity:
Chain Lubrication
Fully automatic, speed-controlled oil
pump. Additional manual oil flow control
Oil tank capacity:
Weight
dry, without bar and chain
3
MS 201 T:
MS 201 TC:
Cutting Attachment
Rollomatic guide bars
Bar lengths (3/8" P
pitch):
Groove width:
3/8" Picco chain
Picco Micro 3 (63 PM3) Type 3636
Pitch:
Drive link gauge:
Picco Super 3 (63 PS3) Type 3616
Pitch:
Drive link gauge:
Picco Duro 3 (63 PD3) Type 3612
Pitch:
Drive link gauge:
0.31 l
Chain sprockets
6-tooth for 3/8" P (spur sprocket)
Other cutting attachments
Other cutting attachments complying
with CSA Standard Z 62.3 are available:
see section CSA-Standard Z 62.3,
0.22 l
"Chain Leaflet" inside chain box or
contact your local STIHL dealer.
Please ask your STIHL dealer to
properly match your powerhead with the
appropriate bar/chain combinations to
3.7 kg
reduce the risk of kickback injury.
3.8 kg
30, 35, 40 cm
1.3 mm
3/8" P
(9.32 mm)
1.3 mm
3/8" P
(9.32 mm)
1.3 mm
3/8" P
(9.32 mm)
1.3 mm
MS 201 T
