LAUNCH
6
7
8
9
10 USB PORT

3.2 Specifications

1) Screen: 2.4" TFT, 320*240 dots LCD display
2) Input voltage range: 9 ~ 18V
3) Operating temperature: 32°F~122°F / 0°C~50°C
4) Storage tempetature: -4°F~158°F / -20°C ~70°C @ RH60%
5) Outline dimension: 120*75*20 mm (L x W x H)
6) Weight : <17.6 oz (500g)

3.3 Accessories

1) User's Manual -- Instructions on tool operations
2) USB cable -- Connect to a computer for upgrading online

3.4 Power supply

The power of the Creader V+ is provided via the vehicle Data Link Connector
(DLC). Follow the steps below to power it up:
1) Locate the vehicle's DLC socket.
A plastic DLC cover may be found for some vehicles and you need to remove
it before plugging the OBDII cable.
2) Plug the connector at the end of OBD II cable to the vehicle's DLC.
8
BUTTON
BUTTON
BUTTON
BUTTON
Creader V+ English User's Manual
Confirms a selection (or action) from a
menu list.
Move cursor left for selection; Or turn
page up when more than one page is
displayed.
Move cursor down for selection.
Move cursor right for selection; Or turn
page down when more than one page is
displayed.
Connects to computer to update the
Creader V+ online.
