Technical data). This enables you to optimise the
cutting speed to suit the surface (see table).
Material
Solid wood (hard, soft)
Chipboard and fibre-
board
Laminated wood,
blockboard, veneered
and coated boards
Plastics, fibre-rein-
forced plastics (GRP),
paper and fabric
Acrylic glass
Plaster and cement-
bonded fibre boards
Aluminium panels and
Al
profiles up to 15 mm
Temperature cut-out
The machine power supply is limited and the speed
reduced if the motor exceeds a certain tempera-
ture. The machine continues operating at reduced
power to allow the ventilator to cool the motor
quickly. If the machine temperature exceeds the
maximum permitted value for longer periods, the
machine switches off completely after approx. 40
seconds and can only be switched on again once the
motor has cooled sufficiently.
Current limiting
Current limiting prevents permissibly high current
consumption under extreme overload, which can
12
All manuals and user guides at all-guides.com
lead to a decrease in the motor speed. The motor
immediately restarts after the load is removed.
Speed
range
The cutting depth can be adjusted to between 0 – 55
6
mm on the cutting depth stop [3-1]:
3-6
The sawing unit can now be pressed down to the set
cutting depth.
6
3-5
4-5
1-3
4-6
+FS

Adjusting the cutting depth

+FS
3
3-1
Cutting depth without guide rails
max. 55 mm
Cutting depth with guide rail FS
max. 51 mm
Included in the scope of delivery you can find a
inch scale for the cutting depth adjustment,
these you can attach optional. This requires that
the scale marks of 0 mm and 0'' match exactly.
