Always wait until the power tool has come to a com-
u
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
Secure the workpiece. A workpiece clamped with
u
clamping devices or in a vice is held more secure than by
hand.
In case of damage and improper use of the battery, va-
u
pours may be emitted. The battery can set alight or ex-
plode. Ensure the area is well ventilated and seek medical
attention should you experience any adverse effects. The
vapours may irritate the respiratory system.
Do not open the battery. There is a risk of short-circuit-
u
ing.
The battery can be damaged by pointed objects such
u
as nails or screwdrivers or by force applied externally.
An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
Only use the battery with products from the manufac-
u
turer. This is the only way in which you can protect the
battery against dangerous overload.
Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture. There is a risk of explosion and
short-circuiting.
Do not touch any application tools or adjacent housing
u
components shortly after operation. These can become
very hot during operation and cause burns.
The application tool may jam during drilling. Make
u
sure you have a stable footing and hold the power tool
firmly with both hands. Otherwise you could lose con-
trol of the power tool.
Take care when carrying out demolition work using
u
the chisel. Falling fragments of the demolition material
could injure you or any bystanders.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.

Intended Use

The power tool is intended for hammer drilling in concrete,
brick and stone. It is also suitable for drilling without impact
in wood and metal, as well as for screwdriving.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) SDS-Quick/hexagonal tool holder
(2) Dust protection cap
1 609 92A 86E | (13.07.2022)
(3) Locking sleeve
(4) Impact/mode selector switch
(5) Right rotational direction indicator
(6) Battery charge indicator
(7) Left rotational direction indicator
(8) Rotational direction switch
(9) On/off switch
a)
(10) Battery
(11) "PowerLight"
a)
(12) Universal bit holder
a)
(13) Screwdriver bit
(14) Screwdriver bit with ball catch
(15) Drill bit with hexagonal shank
(16) Drill bit with SDS-Quick tool holder
(17) Handle (insulated gripping surface)
(18) Battery bay
(19) Battery release button
a)
(20) Keyless chuck
(21) Front sleeve of the keyless chuck
(22) Rear sleeve of the keyless chuck
a) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Cordless rotary hammer
Article number
Rated voltage
A)
Rated speed
A)
Rated speed, 1st gear
A)
Max. torque, 1st gear
A)
Max. torque, 2nd gear
Impact energy per stroke
according to EPTA-Proced-
ure 05:2016
Tool holder
Max. drilling diameter
– Concrete (with twist
drill bit)
– Steel
– Wood
– Masonry
Max. screw diameter
Weight according to EPTA-
B)
Procedure 01:2014
– Recommended ambient
temperature during
charging
a)
a)
a)
a)
a)
Uneo
3 603 J84 0..
V= 12
-1
min 0–900
-1
min 0–280
Nm 14
Nm 30
J 0.5
SDS Quick
Hexagonal
mm 10
mm 8
mm 10
mm 10
mm 6
kg 1.3
°C 0 to +35
