3 Insert tools, accessories

Insert tools
Designation
Hammer drill bits
en
Breach bits
Percussion core bits
PCM diamond core bits
Chisels
Wood drill bits
Metal drill bits
Depth gauge
TE-FY-BA-C adapter
TE-Y-AD adapter
Dust modules TE DRS-BK,TE DRS-B, TE DRS-S
Accessories
Designation
Setting tool
Quick-release chuck
Mixing paddles,with smooth or hex. shank, for mixing
non-flammable, non-hazardous substances

4 Technical data

Right of technical changes reserved.
Power tool
Weight
Dimensions (L ×
W × H)
Power tool
Rated voltage
Rated current input
Mains frequency
Hammer drilling
speed
Single impact en-
ergy (full power)
Other information about the power tool
ATC electronic cut-out
Protection class
4
All manuals and user guides at all-guides.com
TE 70-D/AVR TE 70‑AVR
8.3 kg (18.3 lb) 8.3 kg (18.3 lb)
536 mm (21.1") × 536 mm (21.1") ×
126 mm (4.96") × 126 mm (4.96") ×
305.5 mm (12.03") 305.5 mm (12.03")
TE 70-D/AVR TE 70‑AVR
120 V 120 V
15 A 15 A
60 Hz 60 Hz
360/min 360/min
11.5 J 11.5 J
Description
∅ 12...45 mm (0.47...1.77")
∅ 40...80 mm (1.57...3.15")
∅ 45...150 mm (1.77...5.91")
∅ 42...132 mm (1.65...5.2")
Pointed, flat and shaped chisels with TE‑Y connection
end
∅ 10...32 mm (0.39...1.26")
Up to ∅ 20 mm (0.79")
Item number, description
32221, Setting tool with TE‑Y connection end
60208, Keyless chuck for wood and metal drill bits with
smooth or hex. shank, Chuck holder 263359
41215 (∅80mm), 41216 (∅110mm), ∅ 80...150 mm
(3.15...5.91"), For use only with the keyless
quick-release chuck
TE 70-ATC/AVR
9.5 kg (20.94 lb)
536 mm (21.1") ×
126 mm (4.96") ×
324 mm (12.76")
TE 70-ATC/AVR
120 V
15 A
60 Hz
360/min
11.5 J
TE 70‑ATC/ TE 80‑ATC
Protection class II (double insulated)
TE 80-ATC/AVR
9.7 kg (21.38 lb)
549 mm (21.61") ×
126 mm (4.96") ×
324 mm (12.76")
TE 80-ATC/AVR
120 V
15 A
60 Hz
360/min
11.5 J
