ENGLISH

2. PARTS AND COMPONENTS

FIG.2.
Steam nozzle
1.
Unit base's water tank
2.
Unit base
3.
Main body's water tank
4.
Handle
5.
Button
6.
Indicator
7.
Main body
8.
Brush
9.

3. BEFORE USE

Take the product out of the box.
Make sure all the accessories are included and check for any visible damage. If any is observed,
contact the Technical Support Service of Cecotec.
Remove any sticker or protective element from the steam head.
Unwind and straighten the cord.
Install all the accessories according to this instruction manual, fill the water tank with water,
and then iron a piece of waste cloth twice to remove any posible residues. There will be little
droplets produced for the first use, this is normal.
Note: When operating the garment steamer for the first time, allow it to steam for a few
minutes to remove any impurities and odours that might have been left from the manufacturing
process.
4. OPERATION
Brush: Used for cleaning the stains on the garments such as hair, dust and others.
Main body: Used for producing steam and for cleaning the clothes.
Indicator: Connect the appliance with power source, the indicator starts to blink, and the steam
function can be activated when the indicator remains on.
Button: When the indicator light remains on, press down the button, the appliance will spray
steam.
Handle: The handle is used for controlling the spray angle of the steam.
Main body's water tank: It can be removed for filling water.
18 SMOOTHFORCE 3000/4000 ULTRASTEAM WHITE/BLACK
Unit's base water tank: The water tank of unit base can be removed for filling water.
Unit base: Used for supporting the main body and supplying water to the garment steamer.
Steam nozzle: The garments can be ironed by the steam sprayed out of the steam nozzle.
Using the garment steamer
Remove the unit's base water tank and open the water inlet cover.
Fig. 3.
Fill the water tank of the unit base with cold water and then close the water inlet cover.
Place the main body on the unit base and press it slightly downwards. The main body's water
tank will be automatically refilled with water.
Fig. 4.
Note: If the water tank of main body is not fully filled with water when the appliance is used for
the first time, carefully shake the unit base to exhaust the air in the pipe.
Remove the main body from the unit base once water has been refilled.
Remove the main body's water tank, open the water inlet cover and fill it with the correct
amount of water. Then, place the tank back in its place.
Connect the device to the power supply. The light indicator will blink and the device will start
preheating. Once the device is heated, the light will switch to steady.
If the garment to be ironed is tough or has many creases, iron it for several times.
Install the brush onto the main body to clean stains on garments or to remove hair or other
dust.
Fig. 5.
Note: Do not shake the main body violently during operation.
Fig. 6.
Once you have finished using the garment steamer, unplug it and empty the water in the unit
base.
Fig. 7.
Tips
Some articles can be steamed better by steaming from the underside.
Pants may be steamed holding them by the cuff.
When steaming, touch material lightly with steam nozzle or brush attachment and move up
SMOOTHFORCE 3000/4000 ULTRASTEAM WHITE/BLACK
