Power Edition 40 E - Power Edition 40 E
1
2
3
4
5
6
1 Ein- / usschalter
2 ntriebsbügel
(Power Edition 40 E )
3 Kabelführung (Flick/Flack ® )
4 Kabel-Knickschutz
5 Grasfangsack
6 Griffhöheneinstellung
7 Gangschaltung
(Power Edition 40 E )
8 Sicherheitsbügel
9 Griffbefestigung
10 Kabelzugentlastung
11 Füllstandsanzeige
12 Schutzklappe
13 Schnitthöheneinstellung
14 Schnitthöhenanzeige
1 Interruttore per avviare
2 rchi di azionamento
Power Edition 40 E
3 Slitta (Flick/Flack ® )
4 Regolazione profondità di lavoro
5 Raccolierba
6 Regolazione impugnatura
7 Cambio di marcia
(Power Edition 40 E )
8 rchi di sicurezza
9 Fissare l'impugnatura
10 Portacavo
11 Indicatore di pieno carico
12 Deflettore
13 Regolazione l'altezza di taglio
14 Indicator dell' altezza
4
All manuals and user guides at all-guides.com
7
8
9
10
11
12
1 On-/Off-switch
2 Driving bar
(Power Edition 40 E )
3 Cable-guide (Flick/Flack ® )
4 Cable anti-king protection
5 Grassbox
6 Handle height adjustment
7 Gear shift mechanism
(Power Edition 40 E )
8 Operator presence bail arm
9 Fitting of handle
10 Cable-kink protection
11 Filling indicator
12 Deflector plate
13 Height adjustment
14 Indicator to cutting height
1 In- en uitschakelar
2 andrijfbeugel
Power Edition 40 E
3 Kabelgeleiding (Flick/Flack ® )
4 Knikbescherming
5 Grasvangvoorziening
6 Duwboomhoogte instelling
7 Versnellingen
(Power Edition 40 E )
8 Veiligheidsbeugel
9 Duwboombefestigung
10 Trekontlasten
11 Vulindicator
12 chterklep
13 Maaihoogte instelling
14 Maaihoogte aanwijzing
13
14
1 Interrupteur
2 Etrier du mécanisme d'entraìnement
(Power Edition 40 E )
3 Cable-guide (Flick/Flack ® )
4 Protection antipliage du câble
5 Bac de ramassage
6 Reglage de la hauteur du guidon
7 Embrayage
(Power Edition 40 E )
8 Etrier de sécurité
9 Fixation du guidon
10 Cable-fixe
11 Indicateur du niveau de remplissage
12 Clapet de sécurité
13 Reglage de la hauteur de coupe
14 Cropuis de la hauteur de coupe
